Description

AUTOOL Smoke leakage detection system

Features and Functionality

The AUTOOL SDT206 is a professional-grade smoke machine designed to quickly and accurately detect leaks in automotive systems. By generating dense smoke from baby oil or mineral oil and pushing it into sealed systems, leaks become easy to spot as smoke escapes from faulty areas.

This unit is equipped with dual compressors for consistent output and features both air and smoke test modes, making it suitable for a wide variety of applications including intake systems, exhaust systems, crankcases, fuel tanks, turbo systems, EVAP systems, and other sealed pipe fittings. With adjustable pressure (0–23 PSI) and flow control, it ensures safe and effective testing without damaging sensitive systems like EVAP.

Functions

Intake system leak detection
Exhaust system testing
Crankcase system testing
Fuel tank system testing
Turbo system leak detection
EVAP system testing (with adapters included)
Car sealing test and various pipe fittings test

Additional Details

Built-in protection shuts off power if internal temperature exceeds 75 °C
Intelligent flow and liquid gauges for precise control
Compatible with cars, motorcycles, light trucks, and boats
4 ft smoke outlet hose included for extended reach
Works with baby oil or mineral oil (recommended capacity: 20 ml per fill)
Designed for workshop or professional diagnostic use

Specifications

Specification	Details
Input Voltage	12V DC (powered by vehicle battery)
Output Pressure	0–23 PSI
Smoke Output	0–6 L/min
Heating Material	Mineral oil or baby oil
Modes	Air mode and smoke mode
Hose Length	4 ft
Safety Features	Overheat protection (auto shutoff at >75 °C)
Recommended Oil Capacity	20 ml per fill
Applications	Intake, exhaust, fuel tank, turbo, EVAP, crankcase, and pipe systems
Build Quality	Durable casing with dual compressors

Safe Operation and Maintenance Tips

When you use this AUTOOL SDT206 Car Smoke Leak Detector for the first time, fill it with 20ml oil. Please be careful NOT to fill beyond this range.

The testing liquid: both liquid paraffin and baby oil are OK.

Fresh oil can be filled only when the smoke gets thin, and it can’t be filled over 20ml each time.

Before filling fresh oil, please pour out the left oil in the detector & replace the detector oil regularly.

Do NOT run the detector for over 8 minutes continuously.

The detector has an intelligent protector, if it exceeds the working limit, such as over 75 ℃, it will automatically turn off the power. In this case, please allow it to cool down and operate later.

The round part of this detector reaches hot temps, please be careful to avoid burns.

If the test pipe needs to be disconnected in the middle, please secure the other side with a rubber stopple.
