Launch X431 SmartLink C HD Lite Heavy Duty Truck Module

The Launch X431 SmartLink C HD Lite is a heavy-duty truck diagnostic expansion package designed for professional workshops. It consists of the X-431 SmartLink V2 Heavy-Duty diagnostic module, commonly used non-standard adapters, and a heavy-duty vehicle software package. Compatible with X-431 PRO series 8-inch tablets.

Key Features

• Compatible with X-431 PRO series (8-inch tablets) like the Pros V 5.0
• Full system fault diagnosis: Read/Clear DTCs, Read Data Streams, Special Functions, Actuation Tests
• Bi-directional control for fast troubleshooting (active tests)
• Complies with CAN/DOIP/CAN FD/J2534 protocols
• 75+ supported software packages
• 1 year free software updates included
• VIN Auto Recognition
• Wide vehicle coverage: Trucks, Buses, Construction Machinery, Agricultural Machinery, Natural Gas Vehicles

Vehicle Coverage includes:

Mercedes-Benz, Hino, Neoplan, WABCO, Bosch Diesel, Hyundai, OBD (HD), Western Star, Deutz (Dachai), Case, International, PACCAR, Sinotruk (Xichai), DAF, Caterpillar, Irizar, Peterbilt, Yangchai, Delphi, Chaochai, Quanchai, ZF, Dongfeng Commercial Vehicle, Credo, Isuzu/Chongqing Isuzu, Renault, JAC Commercial Vehicle, FAW Jiefang, IVECO, Aftertreatment System, Mack, Foton Commercial Vehicle, Detroit, JCB, Setel, Perkins, Heavy-Duty ABS, DEUTZ, John Deere, Setra, Scania, AGCO Machinery, Doosan, Kenworth, Sterling, Shaanxi Auto, Aisin, Eaton, MAN, Steyr, Shangchai, Allison, FPT, Maxus, Tata, Sinotruk (CNHTC), Ashok Leyland, Sany, Miller, Voith, Nissan (UD), Commercial Vehicle One-Click Entry System, Freightliner, MWM, Volvo, Guanchai, Bendix ABS, Fuso, Natural Gas, Volvo Construction Equipment, Yuchai, and more.

Engine Systems Supported

Cummins, Bosch, Weichai, Shangchai, Yuchai, Xichai, Chaochai, Yangchai, Quanchai, and more.

Specifications (X-431 SmartLink V2)

• CPU: Dual-processor Cortex-A7 + Cortex-M7
• Operating System: Linux
• Resolution: 320x480
• Power: Less than 6W
• Storage: 8GB
• Memory: 256MB
• Working Temperature: 0°C to 50°C
• Working Voltage: 9V DC to 36V DC
• Dimensions: 200mm x 110mm x 47mm
• Communications: Wi-Fi, Bluetooth, Ethernet

Package Contents

• 1x X-431 SmartLink V2 main unit
• 1x HD15F to OBDII 16-pin Male Integrated Test Adapter
• 1x DB15F to HD15F Test Main Cable (with HD15M to OBDII 16-pin Male Integrated Adapter)
• 1x USB Type-A to Type-B Cable
• 1x Quick Start Guide
• 1x Universal Password Envelope
• 1x Type II OBD-9 Integrated Diagnostic Adapter
• 1x OBD 6 Integrated Diagnostic Adapter
• 1x Caterpillar 9-pin Integrated Diagnostic Adapter (CT9)
• 1x Volvo 8-pin Integrated Diagnostic Adapter (VO8)
• 1x OBD 16 Integrated Diagnostic Adapter
• 1x Heavy-Duty Jumper 10-pin Diagnostic Adapter (JUMPER 10)
• 1x Dual-Clamp Power Cable
• 4x Fuse AC250V/5A
• 4x Electronic Control Adapter Cable 1
• 4x Electronic Control Adapter Cable 6
• 4x Electronic Control Adapter Cable 7
• 4x Electronic Control Adapter Cable 8
• 1x Carrying Case

How to Activate

Go to User Info, select Activate VCI, then enter the device Serial Number and Activation Code found in the password envelope included in the package.
